Frame	Size XL, 500 Series OCLV Carbon, Full System Foil tube shaping, IsoFlow seat tube, RCS Headset System, electronic or mechanical routing, removable aero chainkeeper, T47 BB, flat mount disc, UDH, 142x12mm thru axle
Fork	Madone Gen 8 full carbon, tapered carbon steerer, internal brake routing, flat mount disc, 12x100mm chamfered thru axle
Wheel Size	Front 700c / Rear 700c
Wheels	Bontrager Aeolus Elite 50, OCLV Carbon, Tubeless Ready, thru axle Bontrager Aeolus Elite 50, OCLV Carbon, Tubeless Ready, 100x12mm thru axle Bontrager Aeolus Elite 50, OCLV Carbon, Tubeless Ready, 50mm rim depth, Shimano 11 speed freehub, 142x12mm thru axle
Tyres	Bontrager Aeolus Pro, Tubeless Ready, aramid bead, 120tpi, 700x28mm
Shifter	Shimano 105 R7170 Di2, 12 speed // Shimano 105 R7170 Di2, 12 speed
Front Derailleur	Shimano 105 R7150 Di2, braze-on, down swing
Rear Derailleur	Shimano R7150 Di2, 36T max cog
Crank	Shimano 105 R7100, 50/34, 172.5mm length Praxis, T47 threaded, internal bearing
Cassette	Shimano 105 7101, 11-34, 12 speed
Chain	Shimano SLX M7100, 12 speed
Front Brake	Shimano 105 hydraulic disc, flat mount Shimano CL700, centerlock, 160mm Max brake rotor size
Rear Brake	Shimano 105 hydraulic disc, flat mount Shimano CL700, centerlock, 160mm Max brake rotor size
Handlebar	Bontrager Comp, alloy, 31.8mm, 80mm reach, 121mm drop, 42cm control width, 46cm drop width
Stem	Trek RCS Pro, -7 degree, 110mm length
Seatpost	Madone aero carbon seatpost, 0mm offset, short length
Saddle	Bontrager Aeolus Elite, austenite rails, 145mm width
Weight	8.16 kg
