Trek
2026 Fuel MX 9 X0 AXS Gen 7
£5,825.00Prices include VAT.
Size · L
Colour · BLUE
Out of stock
Currently out of stock.
GTIN 197216271000MPN 5340440
Description
The Fuel MX 9 X0 AXS is a playful trail bike made for hunting down side hits and chasing chaos. Its Alpha NEXT Platinum aluminium frame it paired with a Fox Factory suspension package (150 mm rear, 160 mm front) and MX wheels for a ride that's flickable and zippy. It comes ready to rip with a wireless SRAM X0 Eagle AXS transmission that keeps shifts smooth under load and SRAM Maven Silver 4-piston brakes for massive stopping power.
Specifications
| Frame | Size S, Alpha NEXT Platinum aluminium, internal storage, ZS headset, adjustable leverage rate, guided internal routing, interchangeable alloy rocker link, interchangeable lower shock mount, downtube guard, shuttle guard, BSA 73, ISCG 05, ABP, UDH, Boost148, adaptable travel 145 mm-160 mm Alpha NEXT P |
| Fork | Fox Factory 36, Float EVOL air spring, GRIP X2 damper, 44 mm offset, Boost 110, 15 mm Kabolt X axle, 160 mm travel Fox Factory 36, Float EVOL air spring, GRIP X2 damper, 44mm offset, Boost 110, 15mm Kabolt X axle, 1 |
| Wheel Size | Front 27.5 / Rear 27.5 |
| Wheels | Bontrager Line Comp 30, Tubeless Ready, 6-bolt, Boost110, 15 mm thru-axle, 29" Bontrager Line Comp 30, Tubeless-Ready, Rapid Drive 108, 6-bolt, SRAM XD freehub, Boost148, 12 mm thru axle, 27.5'' |
| Tyres | Maxxis Assegai, tubeless-ready, 3C, EXO+ casing, MAXXGRIP, folding bead, 29x2.5'' // Maxxis Minion DHR II, tubeless-ready, 3C, EXO+ casing, MAXXTERRA, folding bead, 27.5x2.5'' |
| Shifter | SRAM AXS pod SRAM AXS pod |
| Rear Derailleur | SRAM X0 Eagle AXS, T-Type |
| Crank | SRAM X0 Eagle, DUB, 30T steel, T-Type, 55mm chainline, 170 mm length SRAM DUB MTB Wide, 73 m, BSA threaded |
| Cassette | SRAM Eagle XS-1295, T-Type, 10-52, 12-speed |
| Chain | SRAM X0 Eagle, T-Type, 12-speed |
| Front Brake | SRAM Maven Silver 4-piston hydraulic disc // SRAM Maven Silver 4-piston hydraulic disc SRAM Maven Silver 4-piston hydraulic disc // SRAM Maven Silver 4-piston hydraulic disc SRAM HS2, 6-bolt, 180mm // SRAM HS2, 6-bolt, 200mm Max brake rotor size |
| Rear Brake | SRAM Maven Silver 4-piston hydraulic disc // SRAM Maven Silver 4-piston hydraulic disc SRAM Maven Silver 4-piston hydraulic disc // SRAM Maven Silver 4-piston hydraulic disc SRAM HS2, 6-bolt, 180mm // SRAM HS2, 6-bolt, 200mm Max brake rotor size |
| Handlebar | Race Face Turbine, alloy, 35 mm, 40 mm rise, 780 mm width |
| Grips | Trek Line Elite, lock-on |
| Stem | Bontrager Elite, 35 mm, 0-degree, 45 mm length |
| Seatpost | Bontrager Line Dropper, 150mm travel, MaxFlow, internal routing, 34.9 mm, 410 mm length |
| Saddle | Verse Short Comp, steel rails, 145 mm width |
| Weight | 16.17 kg |
