Trek
2026 Fuel EX 9 X0 AXS Gen 7
£5,825.00Prices include VAT.
Size · M
Colour · BLUE
Out of stock
Currently out of stock.
GTIN 197216270737MPN 5340391
Description
Fuel EX 9 X0 AXS is a confident trail bike made to rip into just about anything. It starts with an Alpha NEXT Platinum aluminium frame with a RockShox Ultimate suspension package (145 mm rear, 150 mm front) that make quick work of tech and flow alike. A SRAM X0 Eagle AXS transmission delivers precision wireless shifting that stays smooth under load, while SRAM Maven Silver 4-piston brakes give you the modulation and stopping power you need when things get hairy.
Specifications
| Frame | Size S, Alpha NEXT Platinum aluminium, internal storage, ZS headset, adjustable leverage rate, guided internal routing, interchangeable alloy rocker link, interchangeable lower shock mount, downtube guard, shuttle guard, BSA 73, ISCG 05, ABP, UDH, Boost148, adaptable travel 145 mm-160 mm Alpha NEXT P |
| Fork | RockShox Lyrik Ultimate, DebonAir+ w/ ButterCups, Charger 3.1 RC damper, tapered steerer, 44 mm offset, Boost110, 15 mm Maxle Stealth, 150 mm travel RockShox Lyrik Ultimate, DebonAir+ w/ ButterCups, Charger 3.1 RC d |
| Wheel Size | Front 27.5 / Rear 27.5 |
| Wheels | Bontrager Line Comp 30, Tubeless Ready, 6-bolt, Boost110, 15 mm thru-axle, 29" Bontrager Line Comp 30, Tubeless-Ready, Rapid Drive 108, 6-bolt, SRAM XD freehub, Boost148, 12 mm thru axle, 27.5'' |
| Tyres | Maxxis Minion DHF, tubeless-ready, 3C, EXO+ casing, MAXXGRIP, folding bead, 29x2.5'' // Maxxis Minion DHR II, tubeless-ready, 3C, EXO+ casing, MAXXTERRA, folding bead, 27.5x2.5'' |
| Shifter | SRAM AXS pod SRAM AXS pod |
| Rear Derailleur | SRAM X0 Eagle AXS, T-Type |
| Crank | SRAM X0 Eagle, DUB, 30T steel, T-Type, 55mm chainline, 170 mm length SRAM DUB MTB Wide, 73 m, BSA threaded |
| Cassette | SRAM Eagle XS-1295, T-Type, 10-52, 12-speed |
| Chain | SRAM X0 Eagle, T-Type, 12-speed |
| Front Brake | SRAM Maven Silver 4-piston hydraulic disc // SRAM Maven Silver 4-piston hydraulic disc SRAM Maven Silver 4-piston hydraulic disc // SRAM Maven Silver 4-piston hydraulic disc SRAM HS2, 6-bolt, 180mm // SRAM HS2, 6-bolt, 200mm Max brake rotor size |
| Rear Brake | SRAM Maven Silver 4-piston hydraulic disc // SRAM Maven Silver 4-piston hydraulic disc SRAM Maven Silver 4-piston hydraulic disc // SRAM Maven Silver 4-piston hydraulic disc SRAM HS2, 6-bolt, 180mm // SRAM HS2, 6-bolt, 200mm Max brake rotor size |
| Handlebar | Race Face Turbine, alloy, 35 mm, 40 mm rise, 780 mm width |
| Grips | Trek Line Elite, lock-on |
| Stem | Bontrager Elite, 35 mm, 0-degree, 45 mm length |
| Seatpost | Bontrager Line Dropper, 150mm travel, MaxFlow, internal routing, 34.9 mm, 410 mm length |
| Saddle | Verse Short Comp, steel rails, 145 mm width |
| Weight | 17.08 kg |
