Trek
2026 Fuel EX 9 Eagle 90 Gen 7
£4,925.00Prices include VAT.
Size · XL
Colour · BLUE
Out of stock
Currently out of stock.
GTIN 197216199922MPN 5334945
Description
The Fuel EX 9 Eagle 90 is a confident trail bike made to rip into just about anything. It starts with an Alpha NEXT Platinum aluminium frame with a RockShox Lyrik Ultimate fork and Deluxe Ultimate RC2T shock (150 mm front, 145 mm rear) for confident handling on any trail. A SRAM Eagle 90 transmission gives you fuss-free mechanical shifting that stays smooth under load, while SRAM Maven Bronze 4-piston brakes deliver incredible power for quick stops after steep descents.
Specifications
| Frame | Size S, Alpha NEXT Platinum aluminium, internal storage, ZS headset, adjustable leverage rate, guided internal routing, interchangeable alloy rocker link, interchangeable lower shock mount, downtube guard, shuttle guard, BSA 73, ISCG 05, ABP, UDH, Boost148, adaptable travel 145 mm-160 mm Alpha NEXT P |
| Fork | RockShox Lyrik Ultimate, DebonAir+ w/ ButterCups, Charger 3.1 RC damper, tapered steerer, 44 mm offset, Boost110, 15 mm Maxle Stealth, 150 mm travel RockShox Lyrik Ultimate, DebonAir+ w/ ButterCups, Charger 3.1 RC d |
| Wheel Size | Front 27.5 / Rear 27.5 |
| Wheels | Bontrager Line Comp 30, Tubeless Ready, 6-bolt, Boost110, 15 mm thru-axle, 29" Bontrager Line Comp 30, Tubeless-Ready, Rapid Drive 108, 6-bolt, SRAM XD freehub, Boost148, 12 mm thru axle, 27.5'' |
| Tyres | Maxxis Minion DHF, tubeless-ready, 3C, EXO+ casing, MAXXGRIP, folding bead, 29x2.5'' // Maxxis Minion DHR II, tubeless-ready, 3C, EXO+ casing, MAXXTERRA, folding bead, 27.5x2.5'' |
| Shifter | SRAM Eagle 90, 12-speed SRAM Eagle 90, 12 speed |
| Rear Derailleur | SRAM Eagle 90, T-Type |
| Crank | SRAM Eagle 90, DUB, 30T steel, T-Type, 55 mm chainline, 170 mm length SRAM DUB MTB Wide, 73 m, BSA threaded |
| Cassette | SRAM Eagle XS-1275, T-Type, 10-52, 12-speed |
| Chain | SRAM GX Eagle, T-Type, 12-speed |
| Front Brake | SRAM Maven Bronze 4-piston hydraulic disc // SRAM Maven Bronze 4-piston hydraulic disc SRAM Maven Bronze 4-piston hydraulic disc // SRAM Maven Bronze 4-piston hydraulic disc SRAM HS2, 6-bolt, 180mm // SRAM HS2, 6-bolt, 200mm Max brake rotor size |
| Rear Brake | SRAM Maven Bronze 4-piston hydraulic disc // SRAM Maven Bronze 4-piston hydraulic disc SRAM Maven Bronze 4-piston hydraulic disc // SRAM Maven Bronze 4-piston hydraulic disc SRAM HS2, 6-bolt, 180mm // SRAM HS2, 6-bolt, 200mm Max brake rotor size |
| Handlebar | Race Face Turbine, alloy, 35 mm, 40 mm rise, 780 mm width |
| Grips | Trek Line Elite, lock-on |
| Stem | Bontrager Elite, 35 mm, 0-degree, 45 mm length |
| Seatpost | Bontrager Line Dropper, 150mm travel, MaxFlow, internal routing, 34.9 mm, 410 mm length |
| Saddle | Verse Short Comp, steel rails, 145 mm width |
| Weight | 16.58 kg |
