Frame	Size ML, 500 Series OCLV Carbon, Full System Foil tube shaping, IsoFlow seat tube, RCS Headset System, electronic or mechanical routing, removable aero chain keeper, T47 BB, flat mount disc, UDH, 142x12 mm thru axle
Fork	Madone Gen 8 full carbon, tapered carbon steerer, internal brake routing, flat-mount disc, 12x100 mm chamfered thru-axle Madone Gen 8 full carbon, tapered carbon steerer, internal brake routing, flat mount disc, 12x
Wheel Size	Front 700c / Rear 700c
Wheels	Bontrager Paradigm SL, Tubeless Ready, 24-hole, 21 mm width, Presta valve Bontrager alloy, sealed bearing, CenterLock disc, 100x12 mm thru axle Bontrager alloy, sealed bearing, CentreLock disc, Shimano 11-speed freehub, 142x12 mm thru axle
Tyres	Bontrager R1 Hard-Case Lite, wire bead, 60 tpi, 700x28 mm
Shifter	Shimano 105 R7120, 12-speed // Shimano 105 R7120, 12-speed Shimano 105 R7120, 12 speed // Shimano 105 R7120, 12 speed
Front Derailleur	Shimano 105 R7100, braze-on, down swing
Rear Derailleur	Shimano 105 R7100, 36T max cog
Crank	Shimano 105 R7100, 50/34, 172.5 mm length // Shimano RS520, 50/34, 172.5 mm length Praxis, T47 threaded, internal bearing
Cassette	Shimano 105 7101, 11-34, 12-speed
Chain	Shimano SLX M7100, 12-speed
Front Brake	Shimano RT70, CentreLock, 160 mm Max brake rotor size
Rear Brake	Shimano RT70, CentreLock, 160 mm Max brake rotor size
Handlebar	Bontrager Comp, alloy, 31.8 mm, 80 mm reach, 121 mm drop, 40 cm control width, 44 cm drop width
Stem	Trek RCS Pro, -7-degree, 100 mm length
Seatpost	Madone aero carbon seat post, 0 mm offset, long length
Saddle	Bontrager Aeolus Comp, steel rails, 145 mm width // Verse Short, steel rails, 145 mm width
Weight	8.7 kg
